YOELEO G21 Disc Brake Gravel Bike Frameset
$1,420.00
“Riding into the future of gravel biking, the G21 is the newest masterpiece.”
- Material: Toray 800 Carbon
- Color: Arctic Ice / Desert Brown / Custom Painting
- Frame Weight: Arctic Ice 1150g / Desert Brown 1170g / Raw 1050g (+/-50g, 49cm)
- BB: T47, supports Shimano/SRAM cranks
- Max Tire: 700x53mm / 650Bx2.1”
- Mounts: 4 Bottle / Mudguard / Cargo Rack
- Handlebar: Integrated Carbon, multiple sizes
- UCI Approved
- Description
- Brand
- Reviews (0)
Description
YOELEO G21 DB Disc Brake Gravel Bike Frameset
Unmatched Versatility and All-Terrain Capability
With the ability to accommodate tires up to 53c, the G21 is built for any adventure, adapting effortlessly to various terrains and conditions. This all-around performance makes it the only bike you’ll need, blending speed, stability, and comfort to tackle challenging landscapes and explore new paths.
Customizable Fork Options
The G21 offers two fork choices—one with holes for added versatility in bikepacking and front load attachments, and a minimalist option without holes. Choose based on your needs, whether you're packing light or preparing for fully-loaded adventures.
Advanced Frame and Handlebar Technology
Using ProMoldCore technology, the G21 frame achieves a smooth, wrinkle-free interior, minimizing resin waste and allowing for intricate shapes. The ProMoldCore and ProOne technology in the handlebars enhances stiffness, reduces excess weight, and simplifies cable routing with a seamless finish, providing a pro-level riding experience.
G21 Gallery (some colors are custom paintings, please contact us before ordering)
Specification
Including Parts: G21 Frame, Fork, Handlebar, Seatpost
Frame Size: 45cm, 49cm, 52cm, 54cm, 56cm, 58cm, 60cm
Material: High Modulus Toray 800 Carbon Fiber
Color: Arctic Ice / Desert Brown / Custom Painting
BB: BB T-47 inboard bearing
(Pick the right BB depending on your crank spindle size)
E.g. If you are using a GRX crank: T47 BB inboard bearing for (Shimano) 24mm spindle size.
SRAM DUB / DUB wide crank: T47 BB inboard bearing for SRAM DUB
SRAM GXP: T47 BB inboard bearing for SRAM GXP
BB Width: 86.5mm
Headtube: Straight 1-1/2”
Rear Dropout: 12*142 Thru Axle
Rear Derailleur Hanger: Replaceable
Frame Weight:
Arctic Ice 1150g (49cm) ±50g
Desert Brown 1170g (49cm) ±50g
Raw 1050g (49cm) ±50g
Fork: 1 1/8" - 1 1/2", 12*100 Thru Axle
Tapered Steerer Tube: 1 1/8" Top, 1 1/2" Crown
Fork Weight: G21 Fork: 475±10g (with holes) / G21 Fork: 465±10g (without holes)
Seatpost Weight: 204±15g
Compatibility:
Chainring: Single (Max of 42t for normal crank spindle and 44t for wide crank spindle)
Double (50-34t max with BB to Crank washer)
Brake Fitment: Flat Mount Disc
Cable Routing: Internal
Bottle Mounts: 4
Mudguard Compatible: Yes
Cargo Rack Compatible: Yes
Max Tire Width: 700X53mm, 650BX2.1”
Accessories: Handlebar Spacers 3mm: 1 pc, 5mm: 1 pc, 10mm: 2 pcs, Headset Bearing Cap 10mm: 1 pc
Front Axle: 1 pc, Rear Axle: 1 pc
Limited Rider Weight: 110KG
Sizing and Geometry
| Size | 45 | 49 | 52 | 54 | 56 | 58 | 60 | |
|---|---|---|---|---|---|---|---|---|
| Rider Height | 160cm-168cm | 165cm-175cm | 172cm-180cm | 177cm-185cm | 182cm-190cm | 187cm-196cm | 193cm-201cm | |
| A | SEAT TUBE LENGTH (mm) | 450 | 490 | 520 | 540 | 560 | 580 | 610 |
| B | TOP TUBE LENGTH (mm) | 510 | 515 | 536.4 | 551 | 566 | 577 | 592 |
| C | REACH (mm) | 373 | 373 | 379 | 383 | 387 | 390 | 396 |
| D | STACK (mm) | 512 | 531 | 549 | 566 | 586 | 611 | 640 |
| E | HEAD TUBE LENGTH (mm) | 79 | 98.5 | 107 | 134 | 145 | 171 | 200 |
| F | SEAT TUBE ANGLE | 75° | 75.0° | 75.0° | 73.5° | 73° | 73.0° | 73° |
| G | HEAD TUBE ANGLE | 69° | 69.5° | 70° | 70° | 72.2° | 72.3° | 72.6° |
| H | BOTTOM BRACKET | 79 | 79 | 79 | 79 | 79 | 79 | 79 |
| I | CHAIN STAY LENGTH (mm) | 433 | 433 | 433 | 433 | 433 | 433 | 433 |
| L | FORK RAKE (mm) | 47 | 47 | 47 | 47 | 47 | 47 | 47 |
| M | FORK LENGTH (mm) | 401.5 | 401.5 | 401.5 | 401.5 | 401.5 | 401.5 | 401.5 |
Optional for H21 Intergrated Handlebar ($170.00)
| Handlebar Type | Gravel Bike / Road Bike Handlebar |
| Handlebar Material | 100% Carbon Fiber T800 |
| Finish | UD Matt |
| Decal | Black Glossy |
| Handlebar Stem | 80/90/100/110mm |
| Handlebar Width | 400/420/440mm |
| Angle | 10.2° |
| Reach | 80mm |
| Drop | 120mm |
| Steer Diameter | 28.6mm Compatible |
| Cable Type | Inner Cable / Outer Cable |
| Weight | 376g ± 15g |
| Comes with | Computer Holder, Spacers for rounded 1-1/8 inch (28.6mm) steerer, Top cap and outer cable bearing cover. |
| Standard | EN Standard |
Brand
YOELEO
| Brand Name: YOELEO | Chinese Company Name:厦门优利奥体育用品有限公司 |
| Founded: 2011 | # of Employees: 36 |
| Headquarters: Xiamen, Fujian | Products Categories: Wheels, Frames |
